Manufacturing environments are evolving rapidly transforming both their processes methodologies and connectivity networks to connect new and legacy equipment to harness the power of data. Learn about the industrial Ethernet
The Path to Industry 4.0
Communications infrastructure is the backbone of the connected factory and presents many key opportunities on the path to Industry 4.0. As networks pivot from legacy fieldbus to Industrial Ethernet, multiple challenges emerge within the design and implementation phases. Developing future-proofed, robust, and scalable Industrial Ethernet solutions that can support multiple protocols is a time consuming and resource intensive task. It necessitates a pivot in skillsets and knowledge base to architect systems that ensure data integration, synchronization, and system interoperability. There is, however, a trusted partner who can help you navigate this task, assist in the design and development of seamless, robust Ethernet solutions: Analog Devices.
ADI Chronous™ Products
ADI Chronous™ is a complete portfolio of Industrial Ethernet technologies, solutions, software, and security capabilities designed to connect the real world to factory networks and beyond to the cloud. The ADI Chronous™ portfolio offers multiple port count, low power consumption, and flexible bandwidth. Being multiprotocol, these solutions are compatible with all existing protocols while also providing the ability to future-proof for TSN features.
Features
- Compatible with most existing Industrial protocols
- Future proofed for TSN
- Low latency and power consumption
- Scalable bandwidth
- Security at each node point
- Longevity of supply
Benefits of ADI Chronous™ Products
For Precision Control
For the Harshest Conditions
For Optimized System Design
Industrial Ethernet Embedded Switches
The fido5000 Real-Time Ethernet Multiprotocol (REM) family includes two 2-port Industrial Ethernet platform solution switches that support all major Industrial Ethernet protocols and connect to any processor to build any field device or controller application. ADI embedded Industrial Ethernet switches support selectable bandwidth (10 Mbps, 100 Mbps, and 1 Gbps), and all major Industrial Ethernet protocols including the time sensitive networking features for the IEC/IEEE 60802 industrial profile. They enable connection to any processor type and support fast, convenient development of field devices and automation controllers. Designed to future-proof your system, all ADI multiprotocol Ethernet switches include software drivers that easily integrate with protocol stacks. Specified for extended ambient temperature ranges up to 105°C, ADI embedded Industrial Ethernet switches provide the highest level of reliability needed for industrial applications.
Industrial Ethernet Physical Layer Devices
Industrial Ethernet physical layer devices (PHYs) are designed for robustness in harsh industrial environments. Having completed extensive EMC and robustness testing, these products are ideally suited for applications demanding predictable and secure communications. With industry-leading low latency and low power PHY technology, this portfolio supports data rates of 10 Mbps, 100 Mbps and 1 Gbps. Developed to maximize data transmission and signal integrity, they support multiple MAC interfaces while being housed in small packages. Designed to operate over an extended industrial ambient temperature ranges, Industrial Ethernet physical layer devices provide the highest level of reliability for the Industrial Ethernet applications of today and tomorrow.
Webinar steht noch Online
Evolution of industrial protocols and the latest advances
Fundamentals of industrial Ethernet communication protocols
Sign up to download the Industrial Ethernet e-Book
Delivering Trusted Data in Key Application Areas
ADI’s understanding of network architectures coupled with its application knowledge of how data is collected, processed, and used throughout an operation all serve to inform the security and robust features present in the ADI Chronous offerings.
Deterministic networks and gigabit performance is a requirement of the future factory or process automation system
DI’s Chronous enables synchronization across the boundary of the network into the application, from sub-1 μs right down to the PWM outputs within the servo motor control
Addressing the multiple bandwidth requirements of existing and future intelligent buildings, ADI Chronous provides reliable, secure, and trusted digital communications at all levels of the network.
